4K

121°HFOV & Student Locating

ZC5-F20N

4K

121°HFOV & Student Locating

ZC5-F20N

4K UHD EPTZ
121° Wide HFOV

1/2.8'' CMOS sensor, 8.46 MP, up to 4KP30 video output, support EPTZ; 121°HFOV, enable to frame more, with no distortion.

UHD Lens
Ultra High Definition Lens Gives You a Higher-Definition Vision
  • ZC5-F20N

    Sensor Size

    Pixel

    Focal Length

    Iris

    HFOV

    Digital Zoom

High Definition Images
The camera gives you clear vision of the scenarios at 4K resolution

High-Quality Lenses
Produce High-Quality Images

4KP30 UHD Video Giving Superb Image


Wide-Angle Lens
To Cover More Space of the Scenario

4K UHD
121° Wide Angel

4K Lens with HFOV up to 121°, No Distortion

Interface
Support USB2.0 , LAN

Student Locating
Identify All the People Present
Feature One
Feature Two
Feature Three

In the Full View

Detect and Mark All the People

In the Close - up Shot

Give a Close - up of the Standing People

Can Accurately Detect Multiple People Standing

Applications
Conference/Education


ZC5-F20N
Technical Data
ZC5-F20N
  • Camera
    Image Sensor
    1/2.8" CMOS, 8.46 MP
    Focal Lens
    f=1.64mm
    Iris
    F2.4
    HFOV
    121°
    Shutter Speed
    1/60~1/10,000s
    AGC
    Auto, Manual
    LDC
    Yes
    WDR and Auto Focus Features
    Yes
    White Balance
    Auto, Manual, One Push
    AE Control
    Auto, Manual, Shutter Priority
    MOD (Min Object Distance)
    60 cm
    DOF (Depth of Field)
    From 1.40m up to 16m
  • Interface
    Network
    RJ45 (10M/100M), optional POE; 1.Up to 4KP30; main stream:1080P30/25, 720P30/25,360P30/25; sub stream:4KP30/P25, 1080P30/P25, 720P30/P25, 360P30/P25; Image compression: H.264/H.265; Support HTTP/TCP/UDP/RTSP/RTMP/ONVIF; Support AAC
    USB 2.0
    1.Support UVC; 2.Image compression: H.264/H.265/MJPEG; support 4K, 1080P, 720P, 360P
    Audio Interface
    1 × LINE IN
  • General
    Power
    DC12V; <5W
    Address
    0~63
    Operating Temperature
    0°C ~ +40°C
    Storage Temperature
    -20℃ ~ +60°C
    Dimensions (L×W×H)
    149mm × 76mm × 58mm
    Weight
    ≤0.5kg
