4K

20x/12x, Lecturer Tracking

AMC-G421S/G420B/G431S/G431B

4K

20x/12x, Lecturer Tracking

AMC-G421S/G420B/G431S/G431B

20x UHD & Lecturer Tracking

Up to 20x optical zoom, max outputting 4K ultra-clear images. It enables selection of full-body, half-body or close-up shot ratios for tracking targets.

UHD Lens
Ultra High-Definition Lens Gives You a Higher-Definition Vision
  • AMC-G431S/G431B

    Sensor Size

    Pixel

    Focal Length

    Iris

    HFOV

    Optical Zoom

  • AMC-G421S/G420B

    Sensor Size

    Pixel

    Focal Length

    Iris

    HFOV

    Optical Zoom

20x/12x Optical Zoom
Rich Details

20x/12x Optical Zoom
Crystal Clear from Far or Near

The 20x optical zoom capability enables the camera to meticulously showcase a wealth of high - quality details, delivering images with a remarkable sense of texture and depth.

High Definition Images
The camera gives you clear vision of the scenarios at 4K resolution

Wide Angle UHD Lens
Transmitting Clear Pictures

4KP30 HD video output, equipped with intelligent exposure function, optimizes the image to restore the true color, and the details are clearly visible to improve the efficiency.


Interface
Support HDMI, LAN, USB3.0, 3G-SDI,HDBaseT(Optional)


Extraordinary Intelligent Tracking
Accurate Identification & Stable Tracking
Feature One
Feature Two
Feature Three

In the Crowd

Automatically Identify & Lock Lecturer and Keep Tracking

Strong Ability

Track Even if Lecturer Wears Mask.

Intelligent Adjustment

Auto Adjust Tilt Angle as per Lecturer's Height.

Anti Interference
Not Affected by Moving Objects or External Environment
Feature One
Feature Two
Feature Three

Tilt Motion

while Tracking


Keep Tracking if Lecturer Stand among the Students.

Track Lecturer Only

Not Track Other Moving Object


Track with Lights On /Off

Not Track Moving Objects on Projector.


Applications
Conference/Education/Training/Event


AMC-G421S/G420B/G431S/G431B
Technical Data
AMC-G421S/G420B
AMC-G431S/G431B
  • Camera
    Image Sensor
    1/2.8” CMOS, 8.46MP
    1/2.8” CMOS, 8.46MP
    Focal Length
    4.7~94mm
    3.9~46.8mm
    Iris
    1.6~3.5
    1.6~2.8
    FOV
    59.5°~2.9°
    72.5°~6.3°
    Optical Zoom
    20X
    12X
    Digital zoom
    16X
    Focus System
    Auto, Manual, PTZ Trigger, One Push, Trigger
    Exposure Control
    Auto, Manual, Shutter, Priority, Iris Priority, Bright Priority
    Min. Illumination
    50Lux
    Shutter Speed
    1/50 ~1/10,000s
    AGC
    Auto, Manual
    White Balancee
    AAuto, Manual, Auto Tracking, One Push, Static Color
    SNR
    ≥50dB
    Menu
    Yes
  • PTZ
    Pan
    -170° ~ +170°, 0.1° ~ 120°/s
    Tilt
    -30° ~ +90°, 0.1° ~ 90°/s
    Preset Number
    256
  • Interface
    HDMI 1.4
    1 × HDMI: 4KP30/P25, 1080P60/P50/P30/P25, 720P60/P50/P30/P25
    Network
    1×RJ-45:1×10M/100M, POE supported; 1. Up to 4KP30 video output; 2. Image Compression:H.264/H.265; 3. Protocol: ONVIF/RTSP/RTMP/SRT/TCP/UDP/RTMPS/GB28181; 4. Audio Compression:AAC, G.711; 5. Support Dual streams; 6. NDI Optional
    USB3.0
    1. Support UVC1.1; 2. UVC Support: YUY2/H.265/MJPEG; YUY2:1080P30/P25, 720P30/P25, 480P30/P25, 360P30/P25; H.264/H.265/MJPEG: 4KP30/P25, 1080P60/P50/P30/P25, 720P60/P50/P30/P25, 360P30/P25; 3. UAC Audio Format PCM
    3G-SDI
    1 × 3G-SDI; 1080P60/P50/P30/P25, 720P60/P50/P30/P25
    HDBaseT(Optional)
    4KP30/P25, 1080P60/P50/P30/P25, 720P60/P50; Supports power supply and control, and the transmission distance can reach up to 70 meters
    Audio Interface
    1 × LINE IN, 3.5mm
    Control Interface
    1×RS-232 In, 1×RS-232 Out/RS-485
  • General
    Control Protocol
    VISCA / PELCO-P / PELCO-D
    Power
    DC12V, <15W
    Working Environment
    Temperature:0 ~ +40°C; humidity:10%RH ~90 %RH
    Dimensions(L×W×H)
    211mm × 137mm × 170mm
    Weight
    <1.2kg
